4x4 All Terrain · SUV & Pick-up Truck
The Terra Breaker A/T is designed for 4x4 enthusiasts to conquer extreme traction wherever you go. Ranging from 15 to 22 inch rim diameters, Terra Breaker is suitable for of 4WDs and pick-up trucks requiring outstanding wet performance, durability and long service life.
Performance
All Terrain, All-Season
Specifications
12 PLY, M+S Rated, F-Rated, Rim Protector
Mileage Warranty
50K Miles
Wheel Diameter
15'', 16'', 17'', 18'', 20'', 22''
Available Sizes
24
Thick and strong multi-pitch tread blocks are staggered to improve gripping and braking performance on both paved and gravel roads, allowing longer tread life and on- and off-road durability.
Widened wedge-shaped grooves deliver stronger visual impact while offering higher protection against aquaplaning, heat and road noises.
Multi-angled zigzag sipes improve heat dissipation and water drainage efficiency, enhancing all-season traction and handling on- and off-road.
Concave‑convex shoulder lug bites reinforce grip and skid resistance, offering improved steering and traction on all terrains.
Sawtooth-shaped upper sidewall scallops enable extra ruggedness and puncture resistance by deflecting protruding objects from snagging from sideways.
Stone ejectors attached to block edges add to all-terrain self-cleaning functions by preventing retention and drilling of stones and debris from below the footprint, while tie bars linking across adjacent shoulder blocks effectively reduce tread squirm when rolling and during acceleration and braking, promoting stability that help resist irregular wear and road noises.
| Features | Wheel Diameter | Size | Ply Rating | Load Index & Speed Rating |  |
 |
 |
 |
 |
Standard Rim | Section Width (mm) | Overall Diameter (mm) | Max Load (kg) | Max Load (lbs) | Max Pressure (kPa) | Max Pressure (psi) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
15 | 31x10.50R15LT | 6PR/LRC | 109R | UTQG N/A | Sidewall RWL | Rim Protector | YES | YES | 8.5 | 10.7 | 30.6 | 2270 | 50 | ||
 |
15 | 35x12.50R15LT | 6PR/LRC | 113R | UTQG N/A | Sidewall RWL | Rim Protector | YES | YES | 10 | 12.5 | 34.5 | 2535 | 35 |
| Features | Wheel Diameter | Size | Ply Rating | Load Index & Speed Rating | |
|
|
|
|
Standard Rim | Section Width (mm) | Overall Diameter (mm) | Max Load (kg) | Max Load (lbs) | Max Pressure (kPa) | Max Pressure (psi) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
16 | LT235/85R16 | 10PR/LR E | 120/116S | UTQG N/A | Sidewall RWL | Rim Protector | YES | YES | 6.5 | 9.4 | 31.9 | 3042/2778 | 80 | ||
 |
16 | LT225/75R16 | 10PR/LR E | 115/112R | UTQG N/A | Sidewall RWL | Rim Protector | YES | YES | 6 | 8.7 | 29.4 | 2679/2469 | 80 | ||
 |
16 | LT245/75R16 | 10PR/LR E | 120/116R | UTQG N/A | Sidewall RWL | Rim Protector | YES | YES | 7 | 9.8 | 30.6 | 3042/2778 | 80 | ||
 |
16 | LT265/75R16 | 10PR/LR E | 123/120R | UTQG N/A | Sidewall RWL | Rim Protector | YES | YES | 7.5 | 10.6 | 31.7 | 3415/3085 | 80 | ||
 |
16 | LT285/75R16 | 10PR/LR E | 126/123R | UTQG N/A | Sidewall RWL | Rim Protector | YES | YES | 8 | 11.5 | 32.8 | 3750/3417 | 80 |
| Features | Wheel Diameter | Size | Ply Rating | Load Index & Speed Rating | |
|
|
|
|
Standard Rim | Section Width (mm) | Overall Diameter (mm) | Max Load (kg) | Max Load (lbs) | Max Pressure (kPa) | Max Pressure (psi) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
17 | LT245/75R17 | 10PR/LR E | 121/118R | UTQG N/A | Sidewall RWL | Rim Protector | YES | YES | 7 | 9.6 | 31.7 | 3195/2910 | 80 | ||
 |
17 | LT265/70R17 | 10PR/LR E | 121/118R | UTQG N/A | Sidewall RWL | Rim Protector | YES | YES | 8 | 10.7 | 31.9 | 3195/2910 | 80 | ||
 |
17 | LT285/70R17 | 8PR/LR D | 121/118S | UTQG N/A | Sidewall RWL | Rim Protector | YES | YES | 8.5 | 11.3 | 32.9 | 3195/2910 | 80 | ||
 |
17 | LT305/65R17 | 10PR/LR E | 121/118R | UTQG N/A | Sidewall RWL | Rim Protector | YES | YES | 9 | 12.2 | 32.6 | 3195/2910 | 65 | ||
 |
17 | 35x12.50R17LT | 10PR/LR E | 121R | UTQG N/A | Sidewall RWL | Rim Protector | YES | YES | 10 | 12.5 | 34.5 | 3195 | 65 | ||
 |
17 | P225/65R17 | N/A | 100T | UTQG 560/A/B | Sidewall RWL | Rim Protector | YES | YES | 6.5 | 8.9 | 28.5 | 1874 | 51 | ||
 |
17 | P265/70R17 | N/A | 113T | UTQG 560/A/B | Sidewall RWL | Rim Protector | YES | YES | 8 | 10.6 | 31.7 | 2535 | 51 |
| Features | Wheel Diameter | Size | Ply Rating | Load Index & Speed Rating | |
|
|
|
|
Standard Rim | Section Width (mm) | Overall Diameter (mm) | Max Load (kg) | Max Load (lbs) | Max Pressure (kPa) | Max Pressure (psi) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
18 | LT275/65R18 | 10PR/LR E | 123/120S | UTQG N/A | Sidewall RWL | Rim Protector | YES | YES | 8 | 11 | 32.1 | 3415/3085 | 80 | ||
 |
18 | LT275/70R18 | 10PR/LR E | 125/122S | UTQG N/A | Sidewall RWL | Rim Protector | YES | YES | 8 | 10.8 | 33.3 | 3640/3305 | 80 | ||
 |
18 | 35x12.50R18LT | 10PR/LR E | 123R | UTQG N/A | Sidewall RWL | Rim Protector | YES | YES | 10 | 12.5 | 34.5 | 3415 | 65 | ||
 |
18 | P275/65R18 | N/A | 114T | UTQG 560/A/B | Sidewall RWL | Rim Protector | YES | YES | 8 | 11.1 | 32 | 2601 | 44 |
| Features | Wheel Diameter | Size | Ply Rating | Load Index & Speed Rating | |
|
|
|
|
Standard Rim | Section Width (mm) | Overall Diameter (mm) | Max Load (kg) | Max Load (lbs) | Max Pressure (kPa) | Max Pressure (psi) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
20 | LT275/65R20 | 10PR/LR E | 126/123S | UTQG N/A | Sidewall RWL | Rim Protector | YES | YES | 8 | 11 | 34 | 3750/3415 | 80 | ||
 |
20 | LT305/55R20 | 10PR/LR E | 121/118R | UTQG N/A | Sidewall RWL | Rim Protector | YES | YES | 9.5 | 11.9 | 33.5 | 3195/2910 | 65 | ||
 |
20 | 35x12.50R20LT | 10PR/LR E | 121R | UTQG N/A | Sidewall RWL | Rim Protector | YES | YES | 10 | 12.5 | 34.5 | 3195 | 65 | ||
 |
20 | 35x12.50R20LT | 12PR/LR F | 125R | UTQG N/A | Sidewall RWL | Rim Protector | YES | YES | 10 | 12.5 | 34.5 | 3640 | 80 | ||
 |
20 | P275/55R20 | N/A | 111S | UTQG 560/A/B | Sidewall RWL | Rim Protector | YES | YES | 8.5 | 11.1 | 31.8 | 2403 | 44 |
| Features | Wheel Diameter | Size | Ply Rating | Load Index & Speed Rating | |
|
|
|
|
Standard Rim | Section Width (mm) | Overall Diameter (mm) | Max Load (kg) | Max Load (lbs) | Max Pressure (kPa) | Max Pressure (psi) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
22 | 35x12.50R22LT | 12PR/LR F | 121R | UTQG N/A | Sidewall RWL | Rim Protector | YES | YES | 10 | 12.8 | 35 | 3195 | 65 |
* Availability of products shown above may vary for different countries and regions. Please consult your account manager for local availability. Specifications might subject to changes without further notice.
